Full Automatic Multi-Layer Fresh Chili Pepper Dryer Machine is used to dry chili pepper with hot air circulation, It adopts automatic fresh chili pepper feeding and automatic transport the chili in the dryer oven which makes the drying process full automatically. Multi-Layer Fresh Chili Pepper Dryer Oven Machine can be used for different vegetables and fruits. According to customer capacity requirements, we have different size chili dryer machines for customers. After fresh chili drying. the dry chili moisture content can below 8% which is suitable for chili flakes and chill powder production line.
Features of Multi-Layer Chili Pepper Dryer Oven
- The drying oven with automatic feeding and lifting function.
- The drying oven use multi-layer movable stainless steel belt, make the material auto-turning.
- Hot air through the belt and materials from bottom to top, hot air exchange evenly, fully, high efficiency, products with good quality, and good looks.
- Drying oven designed with cooling and vibration discharge device, output material with low temperature, convenient for packing.
- Drying oven with movable door, easy to clean.
- Also with automatic discharge air cooling bagging device, save labor.
General Structure Drawing of Multi-Layer Mesh Belt Chili Dryer Oven
Specification of Multi-Layer Mesh Belt Chili Dryer Machine
| Specification | Power | Coal Consumption | Space | Garlic Capacity | Spinach Capacity | Chili Capacity |
| 10m,5 layers | 40kw/h | 180kg/h | 16*2.4m | 200-250kg/h | 100-150kg/h | 800-1000kg/h |
| 9m,5 layers | 37kw/h | 120kg/h | 15*2.4m | 180-220kg/h | 90-130kg/h | 500-650kg/h |
| 8m,5 layers | 28kw/h | 100kg/h | 14*2.4m | 120-200kg/h | 50-100kg/h | 450-600kg/h |
Note: Multi-layer dryer oven is customized according to customer requirement.
Working Video of Multi-Layer Chili Dryer Machine
